monochrome interlaced area scan camera
This product has been discontinued and is no longer available. Click the “Contact a JAI engineer” button below to discuss your requirements and explore alternative product options. Please include this camera’s model name in the inquiry form so that we can better assist you.
The TM-773NIR is a monochrome interlaced camera featuring the Sony ICX258 CCD and a traditional RS-170 (EIA) video standard interface. It has large pixels for excellent light gathering ability and NIR sensitivity, plus a collection of advanced features for lens control, auto exposure, and more. It has a 1/3” optical format and a single 15-pin connector for power, camera control, and video output, making installation clean and simple.
The TM-773NIR features an integrated 3-axis control function that can link the camera to auto-iris, auto-focus, and auto-zoom controls or can be used to operate pan & tilt heads or other motorized equipment.
Advanced exposure control for dynamic lighting conditions
TM Series cameras were among the first JAI cameras to offer an Auto Level Control (ALC) option, which combines auto-shutter, auto-gain, and auto-iris into a single integrated function for maximum control over exposure and image quality in outdoor applications or other dynamic lighting conditions.
Small, rugged, and proven in real-world applications
TM Series cameras have been proven in a wide range of industrial, defense, and homeland security applications. Options include conformal coating for damp or high humidity environments and extended temperature capabilities ranging from -40°C to +65°C.
