The GO-5000M-PMCL-1 is a compact industrial area scan camera delivering an excellent blend of size, versatility, and performance, all at an entry-level price. It delivers 5-megapixel monochrome output at up to 107 fps, with flexible ROI and binning capabilities that enable the camera to be tailored to a wide range of machine vision applications.
Like all Go Series cameras, the GO-5000-PMCL-1 measures 29 x 29 x 41.5 mm (excluding lens mount) and weighs only 60 grams enabling it to fit into small spaces or be mounted on vehicles or robot arms where size and weight are critical.
Enjoy 8/10/12-bit monochrome output and use flexible ROI options to adjust your resolution and optical format as required. 2x2 and 4x4 binning lets you turn the 5-micron standard pixels into extra-sensitive 10-micron or 20-micron effective sizes.
Despite its small size and weight, the GO-5000-PMCL-1 is built for the real world, with sturdy housings and extensive shock (80G) and vibration (10G) testing to deliver one of the best MTBF ratings of any small camera – over 180,000 hours. A 3-year warranty is standard.
Versatile 5-megapixel camera with 5-micron pixels and 1” optical format.
Power over Mini Camera Link interface provides high frame rate with minimal trigger latency. Can also be ordered with 4-pin external power connector (GO-5000M-PMCL-EP-1).
Monochrome output.
Analog and digital gain control for less quantized noise in low-light situations.
Single and Multi-ROI modes for flexible windowing and use of 2/3” or smaller optics.
Four built-in HDR modes for up to 84 dB of dynamic range.
2X and 4X binning supported.
Industrial grade performance with 80G shock, 10G vibration, and over 180,000 hrs. MTBF ratings.
Go Series
GO-5000M-PMCL-1
Area Scan
Mono
Visible + NIR
5 MP
2560 x 2048 px
107 fps
Yes
Mini Camera Link (PoCL)
1xCMOS
Lince5M
1 inch
5.0 x 5.0 µm
Global shutter
16.4 mm
12.8 x 10.2 mm
29 x 29 x 51.5 mm
60 g
8/10/12-bit
C-mount
3.24 Watt
-5°C to +45°C
Tripod adapter features mounting holes with 20 mm spacing to fit bottom mounting holes on Go Series and Go-X Series housings. (Note: can be used with top mounting holes on Go-X Series models with Pregius S sensors.)
Standard 1/4-20 attachment to tripods. Includes M3 screws (Depth 5). Only use the supplied screws or other screws having the proper length. Using longer screws can damage internal circuit boards.
Download 2D CAD drawing.
The 26PMCL-02-26PMCL features mini size Camera Link connectors at both ends for attaching to a camera with Mini-CL connectors and a frame grabber with Mini-CL connectors. Per the Power over Camera Link (PoCL) standard, pins #1 and #26 have been reassigned to carry +12V DC power. The cable can, therefore, be used with any JAI camera carrying the MCL or the PMCL model suffix. Length is 2 meters.
A 5-meter version is also available. Ordering number: 26PMCL-05-26PMCL.
The 26PMCL-02-26 CL features a mini size Camera Link connector at one end for attaching to a camera, and a standard size connector at the other end for attaching to standard Camera Link frame grabbers. Per the Power over Camera Link (PoCL) standard, pins #1 and #26 have been reassigned to carry +12V DC power. The cable can, therefore, be used with any JAI camera carrying the MCL or the PMCL model suffix. Length is 2 meters.
Note: This cable can also be used to connect a JAI "CL" model (standard-sized MDR connectors) to a frame grabber with mini-sized (HDR) connectors.
The Go Series cameras are the perfect starting point for a wide range of machine vision applications.
From vision-guided robot arms to autonomous vehicles, Go Series cameras provide high quality images in a compact yet industrial-grade form factor.
Durable Go Series cameras can be configured for a wide range of automotive and automotive parts inspections either as off-the-shelf components or in optional IP67 enclosures.
For simple to complex barcode and OCR-type applications, Go Series cameras provide the desired combination of high image quality and entry-level price.
Go Series cameras fit nicely into systems for inspecting printed circuit boards, sorting small parts, and other electronics-related applications.
Vision systems for track and trace, pill sorting, inspecting vials and ampoules, and many other applications, can all utilize Go Series cameras.
Go Series cameras are the perfect “eyes” for many different types of quality control inspection systems.
