Fusion Series
AD-130GE

JAI's AD-130GE is a 2-CCD multi-spectral prism camera providing simultaneous images of different light spectrums in a single camera - a visible color channel from 400-700nm and a near infrared (NIR) channel from 750-900+nm. This makes it possible to simultaneously inspect surface properties and sub-surface defects.

Simultaneous color and near infrared (NIR) imaging

The visible light channel outputs RGB or Bayer color images spanning the wavelengths visible to the human eye. The NIR channel, on the other hand, “sees” below the surface of organic and other materials to detect imperfections the human eye cannot see.

Replace multiple inspection stations with a single setup

JAI’s prism technology ensures perfect two-channel alignment, allowing users to replace multiple inspection stations with a single setup, providing both ease of use and lower equipment and maintenance costs.

Individual exposure time adjustment for each channel

Separate exposure control for each channel allows the channels to be adjusted to one another without changes in the gain – maintaining a consistent signal-to-noise ratio at all times.

Features
Specifications
Downloads
Accessories

Features

Prism based 2CCD multi-spectral area scan camera that simultaneously captures visible and near-IR light.
Multiple trigger options including Edge Pre-select (timed), Pulse Width Control, and Reset Continuous (RCT) trigger modes.
Sequence trigger mode for on-the–fly change of gain, exposure and ROI.
Delayed readout mode for bandwidth optimization in multi-camera applications.
Blemish compensation built in.
Shading compensation circuit built in.
LUT (Look-up Table) for gamma correction.
AGC (Automatic Gain Control from -3dB to 21dB).
Auto-iris lens video output for use with auto-iris lenses in outdoor or other environments with changing light conditions.
GigE Vision interface, GenICam compliant.

Specifications

Product Line

Fusion Series

Model

AD-130-GE

Type

Area Scan

Color / Mono

Multispectral

Light Spectrum

2-Bands Visible + NIR

Resolution

1.3 MP

Resolution WxH

1296 x 966 px

Frame rate / Line rate

31 fps

ROI

Interface

GigE Vision

Sensors

2xCCD

Sensor Name

ICX447

Optical Format

1/3 inch

Cell Size WxH

3.75 x 3.75 µm

Shutter type

Global shutter

Sensor Diagonal

6.1 mm

Active Sensor Dimensions WxH

4.9 x 3.6 mm

Camera Dimensions HxWxL

55 x 55 x 98.3 mm

Weight

340 g

Video Output

8/10/12-bit

Lens Mount

C-mount

Power Consumption

8 Watt

Operating Temperature (ambient)

-5°C to +45°C

Downloads

Manual & datasheet

Software

Compliance documents

CE Certificate – AD-130GE

PD-12 Power Supply

A universal power supply that works with all JAI cameras equipped with a 12-pin Hirose power connector. Four versions are available:

PD-12UUP U.S. plug with 12-pin Hirose connector to camera

PD-12UEP European plug with 12-pin Hirose connector to camera

PD-12UU U.S. plug, flying leads (no 12-pin connector)

PD-12UE European plug, flying leads (no 12-pin connector)

Download Datasheet

MP-41 Tripod Mounting Plate

Tripod adapter for Fusion Series cameras and some discontinued models with 40 mm spacing between mounting holes.

Only use the supplied M3 screws having the proper length. Using longer screws can damage internal circuit boards.

PC-12P Hirose 12-pin Connector

The HR10A-10P-12S is a universal connector used for power and control signals for many JAI cameras. The connector is a female plug, with sockets, that mates to the connector on the back of the camera. It has soldering cups for easy assembly of custom cables.

12P-02S Power Cable

This cable features flying leads on one end and a Hirose 12-pin connector on the other wired to match the pinout of JAI cameras with 12-pin connectors. The flying leads enable power to be supplied via two of the Hirose pins, while the remaining wires/pins can be utilized to access various I/O functions of JAI cameras (see individual camera datasheets/manuals for functions accessible through the Hirose connectors).

The cables can be used with JAI’s own “flying leads” power supplies, or with third-party or custom power supply systems.

Download Datasheet

Typical applications where Fusion Series industrial cameras are suitable

The Fusion Series area scan cameras are the ideal choice if you have imaging applications where you need to combine visible and NIR imaging inspection.

Fruit and vegetable inspection

Fruit and vegetable inspection simultaneous looking at colors, ripeness, damages, signs of rot under skin, as well as detecting foreign objects (e.g. stones, metal pieces etc).

Inspection of nuts, almonds and olives

The color, size, shape and damage of nuts and almonds can be inspected using the RGB channel, while foreign objects (including olive pits) are more clearly seen with the NIR channel.

Electronics inspection

Inspection of stuffed PCB boards including traces, solder, component placement/alignment, shorting, and other items where color and NIR inspection is important

2D print inspection

Color inspection of magazines and pharmaceutical packaging as well as currency inspection looking at color correctness, water marks and security features woven into the bank notes.

LCD display

Surface inspection of flat panels/displays looking for scratches and defective screen pixels.
