Sweep Series
SW-4000TL-PMCL
4K trilinear line scan

The SW-4000TL-PMCL is a high speed trilinear line scan camera that delivers outstanding color line scan performance for applications that don't require the ultimate precision provided by the prism technology in JAI's Sweep+ Series. Featuring a maximum line rate of 66 kHz for 24-bit RGB output, it is one of the fastest 3 x 4096 color line scan cameras on the market.

Contact a JAI engineer
Product Image Sw 4000 Tl Pmcl Front
Product Image Sw 4000 Tl Pmcl Back

Unique binning and color conversion capabilities

The SW-4000TL-PMCL is the only high-speed trilinear camera to offer support for both vertical and horizontal binning, as well as built-in color space conversions to HSI, CIEXYZ, sRGB, Adobe RGB, and custom RGB color gamuts.

Direct encoder connection

The SW-4000TL-PMCL can be directly connected to rotary encoders, which simplifies setup and enables automatic detection of scan direction for use with reciprocating slide tables. Encoder signals can be daisy-chained from one camera to the next in multi-camera setups.

High speed output

With a maximum line rate of 66 kHz (66,000 lines per second), the SW-4000TL-PMCL is one of the fastest 4K trilinear cameras currently offered. 8/10-bit output is provided over a GenICam compliant Camera Link interface.

Features

  • 4K line scan resolution (4096 pixels per line)

  • One of the fastest 4K trilinear line scan cameras - up to 66 kHz maximum line rate

  • Intelligent sub-pixel spatial compensation and tilted view correction to ensure high image fidelity

  • Supports vertical dual-line binning, 2x horizontal binning, or both

  • Built-in color space conversion to HSI, CIEXYZ, sRGB, Adobe RGB, and more

  • Direct connection to rotary encoders including automatic scan direction detection

  • Flat-field, color shading, and chromatic aberration correction and-push automatic white balancing.

Specifications

Product Line

Sweep Series

Model

SW-4000TL-PMCL

Type

Line Scan

Color / Mono

Color

Light Spectrum

Visible

Resolution

N/A

Resolution WxH

4096 x 1 px

Frame rate / Line rate

66 kHz

ROI

Yes

Interface

Mini Camera Link (PoCL)

Sensors

1xCMOS - Trilinear

Sensor Name

Custom

Optical Format

30.72 mm

Cell Size WxH

7.5 x 7.5 µm

Shutter type

Global shutter

Sensor Diagonal

30.8 mm

Active Sensor Dimensions WxH

30.8 mm

Camera Dimensions HxWxL

62 x 62 x 71.8 mm

Weight

410 g

Video Output

8/10-bit

Lens Mount

F-mount or M-42A mount

Power Consumption

7.8 Watt

Operating Temperature (ambient)

-5°C to +45°C

Demension Image Sw 4000 Tl Pmcl Side

Here are a few applications where Sweep Series trilinear cameras are especially suitable

The Sweep Series trilinear line scan cameras are the perfect starting point for a wide range of color inspection applications.

Print inspection

Inspection of color print materials on web presses including magazines, brochures, flyers, packaging, etc.

Web applications

High-speed inspection of roll-based products including colored films, plastics, textiles, roofing materials, and more.

Waste management/recycling

Sorting of scrap materials, glass, plastics, and other items with various colors and shapes.

Food

Sorting of fruits, produce, and other fresh foods based on color, size, and other parameters.

Semiconductors

Color uniformity on wafer surfaces, patterned wafer inspection, and other wafer/IC defect inspections.

Electronics

Sorting of small parts by color, checking of resistor values, inspection of wiring and component placement on printed circuit boards.

Wood products

Sorting of lumber by color and grain pattern, color matching on laminates and other flooring products.

Tile inspection

Inspection of glazed ceramic tiles
