SP-5000C-USB

Spark Series
SP-5000C-USB
5-megapixel industrial camera

The SP-5000C-USB provides 5-megapixel color resolution at up to 62 fps over a USB3 Vision interface. 5-micron square pixels provide excellent sensitivity while flexible ROI capabilities enable the camera to be tailored to a wide range of high performance applications.

High throughput with plug-and-play convenience

At 62 frames per second over a standard USB3 Vision interface, the SP-5000-USB provides a combination of speed, resolution, and ease-of-use well suited to a wide range high speed inspection applications.

A versatile performer – in monochrome or color

Available in monochrome or color models, the SP-5000-USB supports single and multi-ROI functions enabling users to create the exact resolution and optical format they require for their high performance application.

Auto exposure and high dynamic range

Monochrome models feature a built-in HDR function that lets users to extend the camera’s dynamic range up to 84 dB. In addition, all models feature a P-iris connection and JAI’s Auto Level Control for intelligent exposure control in dynamic lighting conditions.

Features
Specifications
Downloads
Accessories

Features

5-megapixel resolution at up to 62 fps.
1” CMOS imager with global shutter. Raw Bayer color output.
Rohdaten-Ausgabe zur Farbkonvertierung auf dem Rechner.
5 µm square pixels provide excellent sensitivity and optical flexibility.
Analog and digital gain controls for less quantized noise.
P-iris or programmable 3-axis control for motorized lenses, pan/tilt heads, and other analog accessories.
Industrial grade performance with 80G shock, 10G vibration, and -5°C to +45°C operating range.
8/10/12-bit USB3 Vision output for grabberless connection to host computers.

Specifications

Product Line

Spark Series

Model

SP-5000C-USB

Type

Area Scan

Color / Mono

Color

Light Spectrum

Visible

Resolution

5 MP

Resolution WxH

2560 x 2048 px

Frame rate / Line rate

62 fps

ROI

Yes

Interface

USB3 Vision (PoUSB)

Sensors

1xCMOS

Sensor Name

Lince5M

Optical Format

1 inch

Cell Size WxH

5.0 x 5.0 µm

Shutter type

Global shutter

Sensor Diagonal

16.4 mm

Active Sensor Dimensions WxH

12.8 x 10.2 mm

Camera Dimensions HxWxL

62 x 62 x 55.5 mm

Weight

255 g

Video Output

8/10/12-bit

Lens Mount

C-mount

Power Consumption

6.24 Watt

Operating Temperature (ambient)

-45°C to +70°C

Downloads

Manual & datasheet

Software

Compliance documents

GPIO 12-pin Input/Output connector

GPIO & Power 12-pin Input/Output female connector and cord with flying leads. (LKK-IO-12PF-DM)

Connector type end A: 12-pin female Straight (Hirose equivalent).
Connector type end B: Flying leads.

Item number:

31017462: GPIO12p FemFlyingLeads 0.5m LKK-IO-12PF-0.5 (0.5 meter cable)

31017440: GPIO12p FemFlyingLeads 2m, LKK-IO-12PF-02 (2 meter cable).

31017441: GPIO12p FemFlyingLeads 5m, LKK-IO-12PF-05 (5 meter cable).

31017442: GPIO12p FemFlyingLeads 10m, LKK-IO-12PF-10 (10 meter cable).

Note: This item can ONLY be ordered in connection with the camera.(Not available for stand alone orders)

Download datasheet

Power supply unit with 12-pin connector cable

Power supply unit with 12-pin female connector cable - without power cord.
(LKK-PSU-12PF-1.25)

Hirose equivalent connector with cable length of 1.25 meters.

Item number - Power Supply:

31017431: PSU 12-pin 1.25m LKK-PSU-12PF-1.25 (1.25 meter cable length)

Download datasheet

If you plan to include a power supply when ordering our cameras, please remember to also order the appropriate power cord for the power supply.
(Power cords are sold separately from the power supply).

Item numbers - Power Cords:

31017432 (US/Japan): CordPSUTypeA(USJP)1.2m LKK-PSU-PWR-A-1.2 (1.2 meter cable lenght).

31017433 (China): CordPSUTypeI(CN) 1.2m LKK-PSU-PWR-I-1.2 (1.2 meter cable lenght).

31017434 (Europe/Korea): CordPSUTypeC(Euro) 1.5m LKK-PSU-PWR-C-1.5 (1.5 meter cable lenght).

Note: Power supply item and power cords item can ONLY be order in connection with the camera (Not available for stand alone orders).

USB-3.0 cable

USB-3 cable .
(LKK-U3-AM-Micro B-S-DM)

Item number:
31017429: USB3TypeA/MicroA3m LKK-U3-AM-MicroB-S-03 (3 meter cable length)

Note: This item can ONLY be order in connection with the camera (Not available for stand alone orders).

Download datasheet

MP-42 Tripod Mounting Plate

Tripod adapter features mounting holes to fit spacing on Spark Series and (discontinued) Elite Series housings. Standard 1/4-20 attachment to tripods. Includes M3 screws (Depth 5). Only use the supplied screws or other screws having the proper length. Using longer screws can damage internal circuit boards.

Download 2D CAD drawing

High performance, high resolution lens series.

High resolution cameras require high performance lenses capable of delivering sharp images even in applications requiring resolving power of 200 lp/mm and above.
JAI’s selection of high performance, high resolution lenses ensures that you can leverage the small pixel sizes and high level of detail provided by a range of JAI´s high resolution camera models.

For more information on lenses available for the specific camera model, please download our Lens Brochure.

Accessory High Resolution Lenses 370x285px

Compact C-mount lenses

JAI´s compact C-mount lenses are designed to deliver an exceptional combination of performance and price when combined with the state-of-the art sensors found in JAI's machine vision cameras.

The selection includes fixed-focal lengths from 4 mm to 75 mm for different sensor formats. With C-mounts and locking screws on focus and iris settings to ensure reliable operation in typical factory environments.

For more information on lenses available for the specific camera model, please download our Lens Brochure.

Here are a few applications where Spark Series cameras are especially suitable

Spark Series cameras are the perfect starting point for a wide range of machine vision, entertainment, metrology and other applications.

Electronics inspection

Verification of circuit layouts and coatings, ball grid array inspection, component positioning, solder paste quality, dimensional accuracy, pick & place applications, and more.

Sports and entertainment

Spark Series cameras capture high resolution images to track player movement, create virtual environments, generate broadcast replays, and other tasks.

Pharmaceuticals

High speed Spark Series cameras perform detailed inspection of pills, packages, and other pharmaceutical products while maintaining maximum throughput.

Metrology

Many types of industrial parts must be carefully measured to ensure conformance to system requirements. High resolution images enable higher precision on critical measurements.

Automotive spray finish

High speed, high resolution systems identify surface imperfections finer than a grain of salt in final vehicle assembly, to cue operators where to polish and buff out imperfections.
