[DISCONTINUED - NOT FOR NEW DESIGN IN]
Go Series
GO-5000C-USB
compact 5 MP area scan camera

Please contact JAI for replacement options

The GO-5000C-USB is a compact industrial area scan camera delivering an excellent blend of size, versatility, and performance, all at an entry-level price. It delivers 5-megapixel raw Bayer color output at up to 62 fps, with flexible ROI capabilities that enable the camera to be tailored to a wide range of machine vision applications.

Contact a JAI engineer
Product Image Go 5000 C Usb Front
Product Image Go 5000 C Usb Back

Small and lightweight

Like all Go Series cameras, the GO-5000-USB measures 29 x 29 x 41.5 mm (excluding lens mount) and weighs only 46 grams enabling it to fit into small spaces or be mounted on vehicles or robot arms where size and weight are critical.

Outstanding versatility

Choose a monochrome or a Bayer color model depending on your needs, and use flexible ROI options to adjust your resolution and optical format as required. On the monochrome model, 2x2 and 4x4 binning lets you turn the 5-micron standard pixels into extra-sensitive 10-micron or 20-micron effective sizes.

Proven reliability in industrial environments

Despite its small size and weight, the GO-5000M-USB is built for the real world, with sturdy housings and extensive shock (80G) and vibration (10G) testing to deliver one of the best MTBF ratings of any small camera – over 180,000 hours. A 3-year warranty is standard.

Features

  • Versatile 5-megapixel camera with 5-micron pixels and 1” optical format.

  • USB3 Vision interface for plug-and-play convenience.

  • Raw Bayer color output.

  • Analog and digital gain control for less quantized noise in low-light situations.

  • Single and Multi-ROI modes for flexible windowing and use of 2/3” or smaller optics.

  • Industrial grade performance with 80G shock, 10G vibration, and over 180,000 hrs. MTBF ratings.

Specifications

Product Line

Go Series

Model

GO-5000C-USB

Type

Area Scan

Color / Mono

Color

Light Spectrum

Visible

Resolution

5 MP

Resolution WxH

2560 x 2048 px

Frame rate / Line rate

62 fps

ROI

Yes

Interface

USB3 Vision (PoUSB)

Sensors

1xCMOS

Sensor Name

Lince5M

Optical Format

1 inch

Cell Size WxH

5.0 x 5.0 µm

Shutter type

Global shutter

Sensor Diagonal

16.4 mm

Active Sensor Dimensions WxH

12.8 x 10.2 mm

Camera Dimensions HxWxL

29 x 29 x 51.5 mm

Weight

46 g

Video Output

8/10/12-bit

Lens Mount

C-mount

Power Consumption

3.6 Watt

Operating Temperature (ambient)

-5°C to +45°C

Demension Image Go 5000 C Usb Side

Here are a few applications where Go Series industrial cameras are especially suitable

The Go Series cameras are the perfect starting point for a wide range of machine vision applications.

Robotics

From vision-guided robot arms to autonomous vehicles, Go Series cameras provide high quality images in a compact yet industrial-grade form factor.

Automotive

Durable Go Series cameras can be configured for a wide range of automotive and automotive parts inspections either as off-the-shelf components or in optional IP67 enclosures.

Barcode recognition

For simple to complex barcode and OCR-type applications, Go Series cameras provide the desired combination of high image quality and entry-level price.

Electronics inspection

Go Series cameras fit nicely into systems for inspecting printed circuit boards, sorting small parts, and other electronics-related applications.

Pharmaceuticals

Vision systems for track and trace, pill sorting, inspecting vials and ampoules, and many other applications, can all utilize Go Series cameras.

Production quality control

Go Series cameras are the perfect “eyes” for many different types of quality control inspection systems.
